19inch AluminiumTelescopic Handle
- Circular type Deck, forming with one-time, no need any welding, make the mower is much more safely and stronger. and the deck edges fold outward, difference with normally fold inwards, more wind better grass collection
- The lower handle locked directly on Deck, more stronger and saftly when using
- New design of lower handle, together with handle fast fix to make the mower easy folding and storage. Base on the Mow N'Stow engines,allow the end user to store the mower vertically, save storage space and easy to clean the deck and service the blade.
- Special design of rear air path combined with special blade and belt cover design, the air volume is larger, the grass catch efficiency can reach more than 95%
- Blade multi-angle design, and with tooth shape, better effect of mulching
- Fully sealed belt cover design, grass can not enter the bottom of the engine, effectively protect the engine, and make the air flow inside the shell smoother, more wind better grass collection effect.
- AluminiumTelescopic Handle, easy for fold and save storage space
- Circular type Deck, forming with one-time, no need any welding, make the mower is much more safely and stronger. and the deck edges fold outward, difference with normally fold inwards, more wind better grass collection
- The lower handle locked directly on Deck, more stronger and saftly when using
- New design of lower handle, together with handle fast fix to make the mower easy folding and storage. Base on the Mow N’Stow engines,allow the end user to store the mower vertically, save storage space and easy to clean the deck and service the blade.
- Special design of rear air path combined with special blade and belt cover design, the air volume is larger, the grass catch efficiency can reach more than 95%
- Blade multi-angle design, and with tooth shape, better effect of mulching
- Fully sealed belt cover design, grass can not enter the bottom of the engine, effectively protect the engine, and make the air flow inside the shell smoother, more wind better grass collection effect.
- AluminiumTelescopic Handle, easy for fold and save storage space
| Factory Model Name | LMB19S02 |
| Drive Type (Push or self propelled) | Self-propelled |
| Cutting width | 482mm (19inch) |
| Deck material | Steel |
| Engine manufacturer | ZONGSHEN |
| Engine Model and power/displacement | SP150 2.4KW/149CC |
| Engine Max Torque | 7.8N.m |
| Engine Starter System | Recoil |
| Min.fuel consumption(g/Kw.h) | ≤ 395 |
| Cutting Height adjustment | Central adjustment |
| Cutting height | 30-80mm/6 positions |
| Wheels size (Front/Rear) | 8-10 inch (200mm/250mm) |
| Wheels material (plastic or rubber) | Rubber |
| Grass catcher type | Half plastic cover + Fabric bag |
| Grass catcher volume | 70L |
| Discharge Function | Rear bagging /Rear discharge /Mulching/Side discharge |
| Blade type | Straight Blade |
| Throttle control of engine | No |
| Rubber on the upper handle | Yes |
| Fast fix of handle connect for easy fold | Yes |
| Deck front cover | Yes |
| Deck quick washing hole | Yes |
| Gearbox made by (GT or Chinese) | Chinese Gear Box |
| Packing carton dimension | 885x585x530mm |
| Container loading QTY 20GP/40GP/40HC | 96/208/259 |
| Brown box or Color box | brown box |
