SC2300i-H – iPOWER

SC2300i-HX 改型结构数据 AIPOWER.447

SC2300i-HX 改型结构数据 AIPOWER.445

Description
Downloads

Model	Specification	SC2300i-H
Watts	Rated Watts	1800W
Watts	Max. Watts	1900W
Generator	100% copper coil	P
	AVR	P
	AC load(Volts)	230V
	Phase, Frequncy	50HZ
	Max. Amperage	8.3A
Engine	Starting Method	Recoil
	Engine Type	OHV, 4-stroke
	Engine Model	SC80(AP149F)
	Displacement cc	79cc
	Horse Power hp	3.35hp/5500rpm
	Low Oil Shut Down	P
	Fuel Tank Capacity (L)	4.2L
	Fuel Consumption	0.76L/Hr@100% Load
	50% Load (Hrs)	438g/kw.h
	100% Load (Hrs)	466g/kw.h
	Built-in Fual Gauge	P
	Engine Oil Capacity	380ml
Control Panel	Digital Meter	P
	Low Oil Alert Lamp	P
	Circuit Breaker (A)	10A(DC)
	Remote Control	/
	Parallel Output	P
	Eco-Throttle	P
	Socket	European style 250V/16A
	DC Port	12V8.3A USB/1.5A
Others	T.H.D	＜3%
	Battery	/
	Wheel	/
	Spark Plug Socket	E5RTC
	Plug	Europe plug
Packing	Net Weight (kgs)	23
	Gross Weight (kgs）	26
	Packing (LWH, mm)	575375555

Bedienunganleitung

Bedienungsanleitung und CE Zertifikat

Explosion Diagram

Explosion Diagram List

Explosionszeichnung (1.8KW 2300i-H explosive view)
