A5500
| Model | Specification | A5500 |
|---|---|---|
| Watts | Rated Watts | 5KW |
| Max. Watts | 5.5KW | |
| Generator | AC load(Volts) | 230V |
| Phase, Frequncy | 50HZ | |
| Max. Amperage | 21.7A | |
| Voltage Regulation | AVR | |
| Engine | Starting Method | Manual |
| Engine Type | OHV,AIR-COOLED | |
| Engine Model | SC390 | |
| Displacement cc | 389CC | |
| Horse Power hp | 13HP | |
| Low Oil Shut Down | P | |
| Fuel Tank Capacity (L) | 40L | |
| 50% Load (Hrs) | 16 | |
| 100% Load (Hrs) | 12 | |
| Built-in Fual Gauge | P | |
| Engine Oil Capacity | 1.1L | |
| Control Panel | 3-in-1 Meter | P |
| Low Oil Alert Lamp | P | |
| Circuit Breaker (A) | 1P-22A | |
| Socket | European style 2*16A/250V，European style 1*32A/250V | |
| Others | Steel Frame (mm) | 710*536*605 |
| Fold-down Handle | - | |
| Battery | - | |
| Spark Plug Socket | F7RTC | |
| Plug | European style 2*16A/250V，European style 1*32A/250V | |
| Wheel Kits | - | |
| Packing | Net Weight (kgs) | 85 |
| Gross Weight (kgs） | 88 | |
| Packing (L*W*H, mm) | 725*555*640 |
